UV Masking Materials for Sandblasting and Shot Peening

Temporary UV masking materials for sandblasting, dry media blasting, and shot peening need to withstand high velocity impact of organic media, aluminum oxide, cut wire, glass beads, and steel shot. When properly applied and cured with UV light, Panacol UV Masks provide consistent and reliable protection. Their resiliency and strong adhesion prevents edge lift, which preserves the integrity of the surface being protected.

All Panacol UV masks for dry media blasting are designed to be removed by peeling. The peeling process can be accelerated by incorporating a quick hot water dip/rinse prior to peel. Hot air may also be used if practical.  Elevating the temperature of these masks causes them to become more elastic and easier to remove. Multiple viscosities of each product are available to accommodate various dispense methods, which can include dip, spray, or manual application from syringes. Panacol UV masks are available with a color additive to provide appropriate surface contrast for better visibility of coverage during dispensing and removal.

Please view the masking materials listed below for a possible candidate for your sandblasting, gritblasting, or peening process.  Please contact Panacol-USA to confirm your product selection and to secure additional application assistance, including samples and curing process recommendations. In the event that these standard products do not satisfactorily address your performance requirements, Panacol-USA will investigate other solutions that include development of masking materials specifically tailored to the complexity of your application.

Panacol UV masking material provides surface protection during grit blasting.

UV Curing Equipment:

UV system solutions with Panacol UV Masks and innovative curing systems from Honle

Download Brochure:

UV Masking Materials (pdf)

Adhesive Viscosity [mPas] Base Properties Removal Method
Vitralit® MASK 20100 200-400 acrylate Moderate adhesion, water soluble mask, dissolves in hot water Dissolve in hot agitated water
Vitralit® MASK E-20102-G 8,000-15,000 (Rheometer, 25 °C, 10s^-1) acrylate Green color, high adhesion, durable
Peel after hot water soak
(2-3 minutes @ mininmum 176°F/80°C)
Vitralit® MASK 20102-G-Gel 50,000-70,000 acrylate High viscosity, green color,
thixotropic gel version of Vitralit MASK 20102-G
Peel after hot water soak
(2-3 minutes @ minimum 150°F/65°C)
Vitralit® MASK 20104 14,000-17,000 acrylate Translucent, moderate adhesion Peel @ room temperature
Vitralit® MASK 20107 40,000-60,000 acrylate Moderate adhesion Peel after hot water soak, 2-3 minutes @min. 122°F/50°C
Vitralit® MASK 20109 15,000-40,000 acrylate Low adhesion Peel @ room temperature
Vitralit® MASK 20111 30,000-50,000 acrylate Mask for protective coatings,
wave solder, white color
Peel @ room temperature
Vitralit® MASK 20117 20,000-30,000 acrylate Very high adhesion, peelable mask,
green color
Peel after hot water soak
(2-3 minutes @ minimum 150°F/65°C)

To download the technical datasheets (TDS) please click on the adhesive name.
