Electrically Conductive Adhesives

Panacol-USA offers electrically conductive adhesives for applications involving die bonding, underfilling, antennae printing, flip-chips, LCD, and flex circuit assembly.

In select applications, Elecolit® electrically conductive adhesives from Panacol-USA can have significant advantages over traditional soldering methods. Some of their benefits include:

  • Connecting thermally sensitive components – curing occurs at low temperatures (<100°C)
  • Strain relief for electrical connections that experience significant stress during operation
  • Attaching components where connections are not accessible for soldering
  • Electrically conductive adhesives are solvent and lead-free
  • No cleaning or flux is required
  • Easily incorporated into existing assembly processes

Elecolit® electrically conductive adhesives include thermally curable one and two-component products as well as a UV light curable, anisotropic adhesive series. While single component adhesives simplify dispensing and processing, two-component adhesives provide longer shelf life and can be cured at room temperature. The range of adhesive compositions includes epoxies, acrylates, and polyamides. To facilitate practical conductivity, fillers such as silver is used.

View the electrically conductive adhesive products listed below for a possible candidate for your application. Please contact Panacol-USA to confirm your product selection and to secure additional application assistance, including samples and process recommendations. In the event that these standard products do not satisfactorily address your performance requirements, Panacol-USA will investigate other solutions that include development of adhesive specifically tailored to the complexity of your application.

To download the technical datasheets (TDS) please click on the adhesive name.

Contacts on a flexible printed conductor are bonded with conductive silver epoxy adhesive

Electrically Conductive Adhesive Application Viscosity [mPas] Base Curing* Properties
Elecolit® 3012 bonding electroconductive parts
screen printing
paste-like epoxy thermal electrically conductive (ICA)
thermally conductive
suitable for screen printing
Elecolit® 3025 bonding heat-sensitive components 80,000-90,000 2 component epoxy thermal
room temperature
electrically conductive (ICA)
thermally conductive
Elecolit® 3036 bonding heat-sensitive components,
bonding flexible circuits
paste-like 2 component epoxy thermal
room temperature
electrically conductive (ICA)
thermally conductive
Elecolit® 3043 antenna print
bonding ceramic fuses
4,000-5,000 epoxy thermal electrically conductive (ICA)
thermally conductive
Elecolit® 3063 LCD bonding
bonding flexible conductors
150,000-190,000 acrylate UV + pressure
VIS + pressure
electrically conductive (ACA)
Elecolit® 3064 LCD bonding
bonding flexible conductors
gel-like acrylate UV + pressure
VIS + pressure
electrically conductive (ACA)
Elecolit® 3065 bonding flexible circuits
display and touchscreen sealing
paste-like acrylate UV + pressure
VIS + pressure
thermal
electrically conductive (ACA)
transparent brownish color
Elecolit® 323 bonding electronic components paste-like 2 component epoxy thermal electrically conductive (ICA)
thermally conductive
Elecolit® 325 bonding heat-sensitive components paste-like 2 component epoxy thermal electrically conductive (ICA)
thermally conductive
Elecolit® 327 bonding electroconductive parts paste-like polyimid thermal electrically conductive (ICA)
thermally conductive high temperature resistant up to 275°C
Elecolit® 336 bonding heat-sensitive components paste-like 2 component epoxy thermal, room temperature electrically conductive (ICA)
thermally conductive
Elecolit® 342 ESD protection 1,000-2,000 acrylate thermal electrically conductive (ICA)
thermally conductive
Elecolit® 3653 bonding electroconductive parts
ideal for parts subjected to high vibrations
8,000-13,000 epoxy thermal electrically conductive (ICA)
thermally conductive
Elecolit® 3655 LED die attach 5,000-15,000 epoxy thermal electrically conductive (ICA)
thermally conductive
thixotropic
silver color
Elecolit® 3661 bonding flexible interconnect devices 20.000-40.000 epoxy thermal electrically conductive (ICA)
thermally conductive
stable
flexible
Elecolit® 414 printing circuit paths on flexible substrates 20,000-25,000 polyester thermal electrically conductive (ICA)
thermally conductive

*UV = 320 - 390 nm          VIS = 405 nm
